Foam cleaning and/or disinfection unit

Foam cleaning and disinfection units are ideal for cleaning and disinfecting with foam. The foam cleaning and disinfection unit is used in industrial environments where cleaning with foam and/or disinfection is necessary for optimal cleaning. The units are often used in mobile and manual cleaning systems. Read more in the brochure or in the selection plan.

Open brochure Download the selection plan

Advantages

The advantages of a foam cleaning and disinfection unit

Temperature control
Solid construction
Start/stop system
Economical with water
Even dosing
How it works

Request information

A foam cleaning and disinfection unit – how it works

After switching on the unit, the mains water is automatically pressurised. The start-stop system enables the unit to switch on or enter standby automatically when one of the supply points is opened or closed.

The foam cleaning and disinfection system is equipped with a break tank that provides approved backflow protection, which prevents contaminated water from flowing back into the pipes. A dirt trap in the supply line filters the water and prevents unnecessary disruptions.

The proportional dosing system ensures that the chemical is dosed at a constant percentage. The pump recalculates continuously to ensure that the correct amount of chemical is added, depending on the measured water flow. This results in more efficient cleaning and safer use of chemicals.

All units are available with electrically controlled dosing pumps.

Request information

All versions of the foam cleaning and disinfection units

A foam cleaning and disinfection unit is available in various models and with a range of optional extras. This means the unit can always be customised to the specific needs of your company.

CF-Q 6E

6 users foaming
Electrically controlled dosing
Article number: 83604015

CD-Q 6E

6 users disinfecting
Electrically controlled dosing
Article number: 83604016

CFD-Q 64E

6 users foaming
4 users disinfecting
Electrically controlled dosing
Article number: 8360102

Request information

Foam cleaning and or disinfection unit in practice

Frequency-controlled Grundfos IE5 pump

The unit is equipped with a frequency-controlled Grundfos pump. Depending on the number of simultaneous users, the pump regulates the pressure up to a maximum of 8 bar. The keyword here is efficiency, as the pump only uses the energy needed.

Optional Washing Performance Monitor

In a world where sustainability and efficiency are growing ever more important, Elpress offers a solution. Our Washing Performance Monitor lets you check important activities. Water flow, chemical use, cleaning times and other operational information are clearly recorded. The monitor functions like a computer and can be easily linked to a network.

Remote monitoring
